SDR-35
The JBL Synthesis SDR-35 is designed to ensure exceptional performance without compromise and offers an unparalleled feature set that puts it far ahead of the competition. It features full support for Dolby ATMOS, DTS:X, and Auro-3D immersive audio formats. DIRAC Live with Bass Control room EQ with JBL Synthesis system enhancements provides exceptionally accurate system tuning. A full suite of digital and analog connectivity is included along DANTE digital audio networking and HDMI 2.0b (4K Ultra HD) AV switching with support for Dolby Vision and HDR10+ dynamic video, plus IMAX Enhanced certification. Network and Bluetooth streaming are included with Google Chromecast built-in, Apple Airplay 2, Spotify Connect and Tidal Connect, plus it is Roon Ready with Hi-Res and MQA support. Seven channels of Class G amplification are included allowing the SDR-35 to independantly power systems up to 7.1 channels. Full external control allows for complete and easy system integration.
Promotions
Variations
Features
Dolby ATMOS, DTS:X, and Auro-3D Immersive Audio Decoding
DIRAC Live with Bass Control Room EQ
HDMI 2.0b 4K Ultra HD with 8 Inputs and 2 Outputs, Plus Dolby Vision and HDR10+ Compatibility
IMAX Enhanced Certification
Bluetooth and Network streaming included with Google Chromecast built-in, Apple Airplay 2, Spotify Connect and Tidal Connect, plus it is Roon Ready with Hi-Res and MQA support
Class G Amplification 7 x 100WPC into 8 ohms, 140WPC into 4 ohms Plus RCA Analog Outputs
DANTE™ Digital Audio Networking
Specs & Downloads
รายการ# JBLSDR35EU
Product Description
SDR-35
The JBL Synthesis SDR-35 is designed to ensure exceptional performance without compromise and offers an unparalleled feature set that puts it far ahead of the competition. It features full support for Dolby ATMOS, DTS:X, and Auro-3D immersive audio formats. DIRAC Live with Bass Control room EQ with JBL Synthesis system enhancements provides exceptionally accurate system tuning. A full suite of digital and analog connectivity is included along DANTE digital audio networking and HDMI 2.0b (4K Ultra HD) AV switching with support for Dolby Vision and HDR10+ dynamic video, plus IMAX Enhanced certification. Network and Bluetooth streaming are included with Google Chromecast built-in, Apple Airplay 2, Spotify Connect and Tidal Connect, plus it is Roon Ready with Hi-Res and MQA support. Seven channels of Class G amplification are included allowing the SDR-35 to independantly power systems up to 7.1 channels. Full external control allows for complete and easy system integration.
ข้อมูลทั่วไป
Continuous Power Output - 2 channels driven, 20Hz - 20kHz, <0.02% THD
120W@8Ω/200W@4Ω
Continuous Power Output - 2 channels driven, 1kHz, 0.2% THD
140W@8Ω/220W@4Ω
Continuous Power Output - 7 channels driven, 1kHz, 0.2% THD
100W@8Ω/180W@4Ω
Residual noise & hum (A-wtd)
<0.15mV
Maximum input
4.5V rms
Nominal sensitivity
1V, 2V, 4V (user adjustable)
Input impedance
47kΩ
Signal/noise ratio (A-wtd ref 100W) normal/stereo direct
100dB/110dB
Frequency response
20Hz—20kHz ± 0.1dB
Nominal output level
1V RMS (max. 5V RMS)
THD+N (20Hz—20kHz)
–100dB
Headphone Output
Maximum output level into 32Ω
Headphone Output
Output impedance:560Ω
Mains voltage
110–120V or 220–240V, 50–60Hz
Power consumption (maximum)
1.5kW (Thermal dissipation approx. 5200 BTU/hour)
Power consumption (idle, typical)
100W (Thermal dissipation approx. 350 BTU/hour)
Power consumption (standby)
<0.5W
Dimensions W x D (including speaker terminals) x H (including feet)
433 x 425 x 171mm
Weight (net)
40lbs (18.1kg)
Weight (packed)
47.2lbs (21.4kg)
มีอะไรอยู่ในกล่อง
- Remote Control with 2 X AAA Batteries
- Calibration Mic
- Power Cord
- Manual
- USB Cable
- DAB/FM Aerial Antennna
- 3 x Wi-Fi/Bluetooth Antennas
